Friendly-user control panel to easily find and select the functions
All information is shown on the control panel in a very convenient way.
- The patient morphology: adult or child.
- Tooth type: to select the dental pieces to be exposed.
- Image receptor: allows choosing from traditional film, intraoral sensor or phosphor plates.
Modern and clean design to offer you:
- Compact and lightweight tube head.
- Hand switch provided with 3 mt coiled cord.
- Sturdy and stable support arm makes the unit particularly solid, regarding the fixing system and the scissor arm movement.
• Name : Rayme
• Item Classification : 2, Code: A11110 (in Korea)
• Grade : Class Ⅱb (MDD 93/42/EEC as amended by 2007/47/EC)
• Classification : B Type applied part
• Tube Voltage : 70kV(fixed)
• Tube Current : 1mA(fixed)
• X-Ray Tube type : Bipolar fixied X-ray tube
• X-Ray Tube model : DG-073B-DC
• X-Ray Tube Focal Size : 0.3*0.3 mm
• Cooling system : Oil cooling
• Total filtration : 1.6 mm Al
(Inherent filtration : 0.8mm, fixed added filter :0.7 mm Aluminum)
